Versalift VST52 on Morooka
This unit is designed to go where others can’t, assisting access for tree work around live line in the most rural environments, especially where low ground pressure is needed across peaty bogs.
EWP Specifications
| Manufacturer | Versalift |
| Model | VST52 |
| Working height | 16.5m |
| Working radius | 9.5m |
| Insulation | C (46Kv) |
| Boom style | Articulating/Telescopic |
| Boom slew rotation | Continuous |
| Bucket rotation | Yes |
| Bucket capacity SWL | 162kg |
| Bucket dimension (LxWxH) | 1070x610x1100 |
| Control type | Hyd. |
| Bucket lift slide | NA |
| Wrap around bucket (swing Arm) | NA |
| Hydraulic tool port at bucket | Yes |
| Flyboom (°) | NA |
| Auto stow | NA |
| Auto outrigger levelling | NA |
| Jib (material handler) | NA |
| Lifting winch | NA |
Truck Specifications
| Make | Morooka |
| Model | MST 600 VDL |
| Specifications | Tracked carrier |
| HP | |
| Transmisson |
This unit is designed to go where others can’t, assisting access for tree work around live line in the most rural environments, especially where low ground pressure is needed across peaty bogs.
The robust Insulated VST52 is a articulating telescopic boom offering generous reach once on site. The platform has full single stick pressure hydraulic controls to bucket and hydraulic tool port at bucket for hydraulic saws for efficient cutting.
Four out riggers for good correction and stability, 2 radial outriggers at rear, and 2 A frame outriggers on the front. The build is designed to help get the gear to site with a large tool box and tie down points on the deck. Safety handrails fitted to assist bucket access area.
